ATGBICS FTLC1182SDNA 100Base-LR supports a distance of up to 10km over single-mode fibre (SMF) using a wavelength of 1310nm via an LC connector. It uses 4 WDM optical signals, multiplexing them into a single channel for 100Gbps optical transmission. On the receiver side, the module optically de-multiplexes the 100Gbps LR4 inputs into 4 WDM channels signals, and converts them to electrical data. The central wavelengths of the WDM channels are 1295.56nm, 1300.05nm, 1304.58nm and 1309.14nm according to the IEEE LR4 recommendation. Digital optical monitoring (DOM) support is also present enabling real-time monitoring of the parameters of the fibre optic transceiver. Our product is built to the exact specification of Finisar FTLC1182SDNA= and we proudly offer a compatibility guarantee and lifetime warranty. Our rigorously tested products record a unique traceable serial number and are fully compliant with all MSA Standards.
Product Type: CFP Transceiver Module
Compatible OEM: Finisar
|Form Factor||CFP2||Max Data Rate||100Gbps|
|Interface||LC Duplex||Cable Type||SMF|
|DOM Support||Yes||Temperature range||0 to 70°C (32 to 158°F)|
|Compliance Standards||MSA Compliant||Warranty||Lifetime Replacement|
|Dimensions||144.8 x 82 x 13.6mm||Weight||<300 grams|
